Ten lossless PNG crops, ordered left to right, retain all original pixels. At 60 inches tall, the combined trim width is 563.25 inches (46.94 ft), at 89.12 source ppi. Each trim panel is about 56.3 inches wide. These files contain no upsampling or AI detail; print quality depends on viewing distance, media and printer.

Each internal vertical edge includes 12 pixels (about 0.135 inch) of adjacent chart beyond the trim line. This duplicate overlap is for seam alignment; it is not added to the combined trim width. Butt-join at the trim boundaries. Outer chart edges and top/bottom have no bleed. No crop marks, color conversion, printer profiles or invented edge extensions are included.

Use the exact crop and trim coordinates in the panel manifest (dimensions, checksums and layout). Coordinates are half-open pixel bounds in the master. Print at the explicit 60 inch trim height; embedded PNG resolution is approximate and some applications ignore it. Verify scale, seams, required bleed and color with your printer, and proof a representative section before production. No print order has been placed.

• Section 01 — lossless PNG
• Section 02 — lossless PNG
• Section 03 — lossless PNG
• Section 04 — lossless PNG
• Section 05 — lossless PNG
• Section 06 — lossless PNG
• Section 07 — lossless PNG
• Section 08 — lossless PNG
• Section 09 — lossless PNG
• Section 10 — lossless PNG

Untouched original PNG (519.09 MiB) · Source and reuse metadata. Source: David Rumsey Map Collection via Wikimedia Commons; Commons identifies the image as public domain in the US, with possible restrictions elsewhere.
